230V controller for tubular operator systems with adjustable run time, selectable impulse or direction commands, two operating modes and photocell facility.
Specifications: Adjustable Run time; Selectable impulse or direction commands; 2 Operating modes; Voltage: 230 VAC +10% – 15% 50-60Hz; Current: INPUT 5W; Motor Output: 1000W Max.
Easy-to-install controller for tubular operator systems.
| FEATURES | |
|
|
| SPECIFICATIONS | |
| VOLTAGE | 230 VAC +10% / -15% 50-60Hz |
| CURRENT INPUT | 5W |
| MOTOR OUTPUT | 1000W max |
| RECEIVER LOAD (ON MAINS) | 4.4W max |
| MAXIMUM NUMBER OF STORED TRANSMITTERS | 1000 |
| TEMPERATURE RANGE | -10ºC to +55ºC |
| FUSE | 6.3A anti-surge |
| DIMENSIONS | 145 x 300 x 85mm |
| MAXIMUM MOTOR LOAD | 1000W (230VAC) |
| MAXIMUM LIGHT LOAD | 500W (230VAC) |
AE900 Controller 230V for Tubular Operator Systems Datasheet (PDF)
