DorGO 800

R4, 330.00

Sectional Garage Door Operator – Dortech

Specifications: Easy Installation with Quick & Easy Step-by-step Programming; Soft Start, Soft Stop; Obstacle Sensing Feature; Speed: 140 mm/sec approx; Protection: Internal use.

FEATURES
Easy Installation with Quick & Easy Step-by-step Programming Soft Start, Soft Stop Obstacle Sensing Feature Accurate Limits LED Lighting Chain Rail System Battery Backed Quiet 2 Year Product Warranty Includes 2 remotes (27A 12V x1 battery)
SPECIFICATIONS
SUPPLY VOLTAGE	230V AC – 50Hz
CONTROL VOLTAGE	24VDC
MOTOR POWER	120W
DRIVE	800 N
IP RATING	IP20
SPEED	140 mm/sec approx.
LIFT CAPACITY	Doors up to 12m² and 100 kg
TEMPERATURE RANGE	-30 – +65° C
PROTECTION	Internal use
WEIGHT	4.9 kg
RAIL LENGTH	3.3m – max travel 2.5m
REMOTE CONTROLS	433Mhz – (Rolling Code) range ± 25m (Battery)
BATTERY BACKUP	1.2AH (Standard) – 3.5AH (Optional)
CHAIN RAILS	Rail Length – Opening height
