Econo Controller 500DC-750DC

A versatile and intelligent DC motor controller designed to manage gate and door systems rated between 500 kg and 750 kg. Engineered for smooth, reliable operation, it combines advanced control logic with built-in safety features, making it ideal for residential and light commercial applications. The controller supports precise movement control, configurable settings, and seamless integration with a wide range of safety and access devices.

Full Specifications:

Motor compatibility: 500–750 kg DC motors
Supply voltage: 230V AC (input)
Motor output: 24V DC
Motor type: DC gate/door motors
Control modes: Open, Close, Stop, Pedestrian mode (configurable)
Logic control: Microprocessor-based with programmable functions
Soft start/stop: Adjustable ramp-up and ramp-down for smooth operation
Force control: Adjustable motor force and torque settings
Obstacle detection: Electronic safety with auto-reverse function
Inputs:
Photocells / safety beams
Push button / key switch
Safety edges
Outputs:
Relay outputs for accessories
Status indication outputs
Receiver compatibility: Integrated or external Easywave receiver support
Memory: Programmable transmitter memory (expandable depending on receiver)
Operating temperature: -20°C to +60°C
Protection class: IP-rated enclosure (controller dependent)
Installation: Wall-mounted control unit
Applications: Sliding gates, swing gates, and automated door systems.

(The Company reserves the right to amend product specifications and information without notice.)
