KD 50 Chain Drive

The KD 50 is designed for specialised, high-load industrial applications requiring exceptional power and durability. Built to handle the most demanding roller shutter doors, it delivers consistent performance under extreme conditions.

When paired with an appropriate safety catch system, the KD 50 provides a reliable and high-performance solution for large-scale industrial door operations.

Key Features

• Extreme torque for large industrial doors
• Heavy-duty construction
• Designed for high-load applications
• Reliable and consistent operation
• Suitable for specialised industrial use


  KD 50 — Specifications

  Specification	Details
  Model	KD 50
  Application	Extra-large industrial roller shutter doors
  Power Supply	400V (Three Phase)
  Motor Type	AC Industrial Motor
  Output Torque	Approx. 500 Nm
  Drive Type	Worm Gear Drive
  Limit System	Mechanical or Encoder Limits
  Duty Cycle	Heavy Duty / Continuous Use
  Mounting	Chain Drive (Indirect)
  Protection Rating	IP54
  Safety	Requires safety catch system
  Usage	Industrial / High Load Applications
